Solar Charge Controller Calculator

Size the right charge controller for your solar panel array

Controller Size

50A

Array

800W

Charge

33.3A

Controller Size
50A
Min Amps
41.7A
Total Array
800W
Max Input V
96V

Daily production: ~166.7 Ah (at 5 peak sun hours)

Safety factor: 1.25x applied to controller sizing

Example Calculations

1800W Array / 24V Battery

Inputs

Panels2x 400W
Battery24V
TypeMPPT

Result

Controller50A MPPT

2200W Portable / 12V

Inputs

Panels1x 200W
Battery12V
TypeMPPT

Result

Controller30A MPPT

Frequently Asked Questions

Q

How do I size a solar charge controller?

Divide total panel wattage by battery voltage, then multiply by 1.25 safety factor. For 800W panels on a 24V battery bank: 800/24 × 1.25 = 41.7A, so use a 50A MPPT controller.

  • MPPT: amps = (total watts / battery voltage) × 1.25
  • PWM: amps = (total panel current) × 1.25
  • Round up to next standard controller size
  • Common sizes: 20A, 30A, 40A, 50A, 60A, 80A, 100A
  • Always include 25% safety margin
Q

What is the difference between MPPT and PWM?

MPPT controllers convert excess panel voltage into additional current, gaining 20-30% more energy than PWM. PWM directly connects panels to batteries so panel voltage must match battery voltage. MPPT is better for all systems over 200W.

  • MPPT: 20–30% more efficient than PWM
  • MPPT: panels can be higher voltage than batteries
  • PWM: panels must match battery voltage
  • PWM: cheaper, simpler, for small systems
  • MPPT: required for systems over 200W
Q

What battery voltage should I use?

Use 12V for small systems under 500W, 24V for 500-2000W systems, and 48V for larger systems over 2000W. Higher voltage means lower current and thinner wires.

  • 12V: small systems under 500W
  • 24V: medium systems 500–2,000W
  • 48V: large systems over 2,000W
  • Higher voltage = lower current = thinner wires
  • 48V most efficient for long wire runs
Q

Can I oversize my charge controller?

Yes, a larger controller than needed is fine and provides room for future expansion. Never undersize though - the controller current rating must exceed the calculated maximum current with safety factor.

  • Oversizing is safe and allows expansion
  • Undersizing can damage the controller
  • Controller will only pass what batteries need
  • Max input voltage must not be exceeded
  • Check Voc (open circuit voltage) of panels
