Radiant Floor Calculator — PEX Tubing Estimator

Calculate PEX tubing length, rolls, and material costs for radiant floor heating

Units

PEX Tubing Needed

480 ft

Area

300 sq ft

Materials

$1,760

Include sub-floor insulation

Material Estimate

Total PEX Tubing
480 ft
2 rolls (300 ft each)
Heat Output
9,000 BTU
Coverage
300 sq ft

Cost Breakdown

PEX Tubing$360
Manifold (2 zone)$500
Insulation$450
Mixing valve$350
Fittings$100
Materials Total$1,760
Professional Install$1,800 – $3,600

Loop Spacing Guide

SpacingBTU/sq ftBest For
6"40High heat loss, bathrooms
9"30Standard rooms
12"25Well-insulated, supplemental

Find an HVAC Technician Near You

Get free quotes from HVAC professionals near you

100% freeNo obligation2-minute match
Angi
Angi4.7/5

Verified reviews & background checks

Get Free Quotes

We may earn a commission when you request quotes, at no extra cost to you.

Showing results for your area

Find an HVAC Technician Near You

Get free quotes from HVAC professionals near you

100% freeNo obligation2-minute match
Angi
Angi4.7/5

Verified reviews & background checks

Get Free Quotes

We may earn a commission when you request quotes, at no extra cost to you.

Showing results for your area

Related calculators

Heat Loss CalculatorHome heat loss analysisBTU CalculatorHeating BTU sizingFlooring CalculatorFlooring materialsRadiant Floor Heating Installation Cost CalculatorEstimate 2026 radiant floor heating install cost. Electric mats $10–$20/sqft ($1,500–$4,000 bathroom); hydronic whole-home with boiler $15,000–$50,000.Geothermal Installation Cost CalculatorEstimate 2026 geothermal installation cost by loop type, home size, and tonnage. Vertical wells $25,000–$45,000, horizontal loops $20,000–$30,000 pre-ITC.Natural Gas vs Propane Heating Cost Calculator — 2026 $/MMBTUCompare natural gas vs propane home heating cost on an energy basis ($/MMBTU): yearly running cost, 15-year total, and break-even year. See which fuel wins.

Example Calculations

1Standard Bathroom (10×12 ft, 6" spacing)

Inputs

Room10 ft × 12 ft
Spacing6 inches
TubingPEX-A

Result

PEX Needed304 ft (1 roll + header)

120 sq ft / 0.5 ft spacing = 240 ft. Plus 10% turns (264 ft) + 20 ft header = 284 ft. 1 roll of 300 ft.

2Living Room (20×15 ft, 9" spacing)

Inputs

Room20 ft × 15 ft
Spacing9 inches
Zones2

Result

PEX Needed480 ft (2 rolls)

300 sq ft / 0.75 ft = 400 ft. Plus 10% (440 ft) + 40 ft headers (2 zones) = 480 ft.

Frequently Asked Questions

Q

How much PEX tubing do I need for radiant floor heating?

Divide your floor area by the loop spacing (in feet), then add 10% for turns and headers. A 300 sq ft room with 9-inch spacing needs about 440 linear feet of PEX tubing plus 20 feet per manifold zone for headers.

  • 9-inch spacing (standard): floor area / 0.75 ft × 1.10 = total PEX feet
  • 6-inch spacing (high output): floor area / 0.50 ft × 1.10 for bathrooms and exterior walls
  • 12-inch spacing (supplemental): floor area / 1.0 ft × 1.10 for well-insulated spaces
  • PEX comes in 300 ft rolls; plan circuits to avoid joints under the floor
Q

What loop spacing should I use for radiant floors?

Standard 9-inch spacing works for most rooms at 30 BTU/sq ft output. Use 6-inch spacing for bathrooms and high heat loss areas (40 BTU/sq ft), and 12-inch for well-insulated supplemental heating (25 BTU/sq ft).

  • 6" spacing: maximum heat output, best for tile floors over uninsulated slabs
  • 9" spacing: standard for most rooms, provides comfortable even heating
  • 12" spacing: lower output, used with well-insulated homes or as supplemental heat
  • Never exceed 12" spacing; uneven floor temperatures cause cold spots between loops
Q

How much does radiant floor heating cost?

Materials cost $6–$12 per square foot for a hydronic system including PEX, manifold, insulation, and controls. Professional installation adds $6–$12/sq ft. A 300 sq ft room costs $3,600–$7,200 total.

  • PEX-A tubing: $0.65–$0.85/ft; PEX-B: $0.40–$0.55/ft
  • Manifold: $200–$400 per zone including valves and flow meters
  • Sub-floor insulation: $1.25–$1.75/sq ft for R-10 rigid foam panels
  • Mixing valve and pump: $300–$600 depending on system size
Q

What is the best PEX type for radiant floors?

PEX-A (expansion method) is preferred for radiant floors because it has shape memory and fewer fittings. PEX-B works but is stiffer and harder to bend around tight turns. PE-RT is a newer alternative that can be heat-welded.

  • PEX-A: most flexible, can be bent to tighter radius, self-heals from kinks
  • PEX-B: 30–40% cheaper, adequate for straight runs and gentle curves
  • PE-RT: weldable connections, no expansion fittings needed, gaining popularity
  • All three types use oxygen barrier versions for hydronic heating systems
