Cold Frame Calculator — Dimensions, Glazing & Lumber

Plan cold frame dimensions, glazing sheets, and lumber for season extension

Growing Area

18 sq ft

Glazing Sheets

2

Hinges

2

Units

Total Growing Area

18 sq ft

Glazing Sheets

2

Frames

1

Materials

Glazing Sheets2
2\u00D76 Lumber (lin ft)18
2\u00D712 Lumber (lin ft)12
Hinges (pairs)2

Find a Landscaper Near You

Get free quotes from landscaping professionals near you

A
Angi4.7/5

Verified reviews & background checks

Get Free Quotes

Showing results for your area

Example Calculations

1Standard 6×3 ft Polycarbonate Frame

Inputs

Length6 ft
Width3 ft
Back Height18 in
Front Height12 in
GlazingPolycarbonate
Frames1

Result

Growing Area18 sq ft
Glazing Sheets2
Hinges2

Area = 6 × 3 = 18 sq ft. Lid area = 18 sq ft. Polycarbonate sheets (16 sq ft each) = ceil(18/16) = 2.

2Two 4×4 ft Glass Frames

Inputs

Length4 ft
Width4 ft
Back Height18 in
Front Height12 in
GlazingGlass
Frames2

Result

Growing Area32 sq ft
Glazing Sheets4
Hinges4

Area = 4×4×2 = 32 sq ft. Lid area = 32 sq ft. Glass sheets (8 sq ft each) = ceil(32/8) = 4.

Frequently Asked Questions

Q

What size should a cold frame be?

A standard cold frame is 3×6 ft (18 sq ft) for easy reach from one side. The back should be 18 inches tall and the front 12 inches for proper water runoff and sun angle. Wider frames (4 ft) need access from both sides.

  • Standard: 3×6 ft for single-side access
  • Wide: 4×8 ft with access from both sides
  • Back height: 16–18 inches for proper drainage angle
  • Front height: 10–12 inches
  • Face south for maximum sun exposure
Q

What glazing material is best for cold frames?

Twin-wall polycarbonate is the best overall choice — it insulates better than glass, is shatterproof, and lasts 10+ years. Glass is heavier but provides slightly more light. Polyethylene film is cheapest but needs yearly replacement.

  • Polycarbonate: best insulation, shatterproof, lasts 10+ years
  • Glass: maximum light, heavy, breakable
  • Polyethylene film: cheapest, replace annually
  • 6mm polycarbonate has R-value of 1.5 vs glass at 0.9
  • UV-treated poly film lasts 2 seasons vs 1 for untreated
Q

How much warmer is a cold frame than outside?

A cold frame raises temperatures 10–20°F above ambient during the day and 5–10°F at night. Double-glazed frames retain more heat. Adding thermal mass (water jugs) inside provides additional overnight warmth.

  • Day: +10–20°F above ambient temperature
  • Night: +5–10°F above ambient
  • Double glazing adds 3–5°F more retention
  • Black water jugs add 5°F overnight (thermal mass)
  • Ventilation needed above 70°F to prevent overheating
Q

What lumber do I need to build a cold frame?

Use 2×6 or 2×12 cedar or pressure-treated lumber for the box sides. You need two long boards and two short boards per frame, plus 2×2 strips for the lid frame. Cedar lasts 10–15 years without treatment.

  • Sides: 2×6 or 2×12 cedar or pressure-treated
  • Lid frame: 2×2 strips around glazing perimeter
  • Hinges: 2 per lid (galvanized or stainless steel)
  • Hardware: screws, corner brackets, prop stick
  • Cedar is naturally rot-resistant without chemicals
