Load Status
OK
Total Load
12,240 lbs
Per Stud
816 lbs
Safety Factor
6.13
Structure has adequate load capacity with a comfortable safety margin.
12,240 lbs
6.13
816 lbs
5,000 lbs
Inputs
Result
Tributary area = 12 × 12 = 144 sq ft. Total load = 85 × 144 = 12,240 lbs. Studs = (20 × 12) / 16 = 15. Per stud = 12,240 / 15 = 816 lbs. Safety factor = 5,000 / 816 = 6.13.
Inputs
Result
Tributary area = 14 × 14 = 196 sq ft. Total load = 130 × 196 = 25,480 lbs. Studs = (24 × 12) / 16 = 18. Per stud = 25,480 / 18 = 1,416 lbs. Safety factor = 8,000 / 1,416 = 5.65.
Total load = (roof load + floor load + dead load) × tributary area. Then divide by the number of studs to get per-stud load. Compare against allowable loads for your stud material and spacing.
A safety factor of 1.5 or higher is generally considered safe for residential wood-frame construction. Between 1.0 and 1.5 is marginal and may need engineering review. Below 1.0 means the structure is overloaded.
| Safety Factor | Rating | Action Required |
|---|---|---|
| Below 1.0 | Overloaded | Reinforce immediately |
| 1.0–1.25 | Marginal | Engineering review recommended |
| 1.25–1.5 | Acceptable | OK for standard residential |
| 1.5–2.0 | Good | Comfortable safety margin |
| 2.0+ | Excellent | Exceeds typical requirements |
A single 2×4 stud at 8 feet tall can support approximately 5,000 lbs of axial load. A wall with 16" on-center spacing has studs every 16 inches, so a 20-foot wall has about 15 studs sharing the total load.
| Stud Size | Axial Capacity (8 ft) | Axial Capacity (10 ft) | Common Use |
|---|---|---|---|
| 2×4 | ~5,000 lbs | ~4,250 lbs | Interior and exterior walls |
| 2×6 | ~8,000 lbs | ~6,800 lbs | Exterior / heavy load walls |
| 2×8 | ~12,000 lbs | ~10,200 lbs | Commercial / multi-story |
Tributary area is the floor or roof area that transfers its load to a specific wall or column. For a wall running through the center of a building, the tributary area extends halfway to the next parallel support on each side.
