Example Calculations

120A Kitchen Circuit (120V, 50 ft, 12 AWG Copper)

Inputs

Current20 amps

Voltage120V

Distance50 ft

Wire12 AWG Copper

Result

Voltage Drop2.65% (3.18V)

Ampacity (75°C)25A

Max Distance (3%)56 ft

12 AWG copper resistance = 1.588 ohm/1000ft. Drop = 20 × 1.588 × 100/1000 = 3.18V. Percent = 3.18/120 = 2.65%.

230A Dryer Circuit (240V, 40 ft, 10 AWG Copper)

Inputs

Current30 amps

Voltage240V

Distance40 ft

Wire10 AWG Copper

Result

Voltage Drop1.0% (2.4V)

Ampacity (75°C)35A

Max Distance (3%)120 ft

10 AWG copper resistance = 0.999 ohm/1000ft. Drop = 30 × 0.999 × 80/1000 = 2.4V. Percent = 2.4/240 = 1.0%.

Show all examples

Frequently Asked Questions

What is the maximum acceptable voltage drop?

NEC recommends no more than 3% voltage drop for branch circuits and 5% total for feeder + branch combined. At 120V, 3% = 3.6V drop. Longer wire runs need thicker gauge to stay within limits.

Branch circuit limit: 3% voltage drop (NEC recommendation)
Total system limit: 5% (feeder + branch combined)
At 120V, 3% = 3.6V maximum drop
At 240V, 3% = 7.2V maximum drop
Voltage drop increases linearly with distance and current

Voltage	3% Drop	5% Drop	Impact
12V DC	0.36V	0.6V	LED dimming, motor slowdown
120V AC	3.6V	6V	Lights dim, motors run hot
240V AC	7.2V	12V	Reduced appliance efficiency

What wire gauge do I need for 20 amps?

12 AWG copper wire handles 20 amps at 75°C rating per NEC Table 310.16. For runs over 50 feet at 120V, consider upsizing to 10 AWG to keep voltage drop under 3%. Aluminum wire requires one gauge larger than copper.

14 AWG: 15 amps (typical 15A household circuits)
12 AWG: 20 amps (kitchen, bathroom, garage circuits)
10 AWG: 30 amps (dryers, water heaters)
8 AWG: 40–50 amps (ranges, large appliances)
6 AWG: 55–65 amps (sub-panels, large A/C units)

How far can you run 12 gauge wire?

At 20A and 120V, 12 AWG copper can run about 50 feet one-way before hitting 3% voltage drop. At 10A, it can go about 100 feet. Lower current or higher voltage extends the safe distance.

20A at 120V: ~50 feet one-way (3% limit)
15A at 120V: ~65 feet one-way
20A at 240V: ~100 feet one-way
Double distance by halving current
Double distance by doubling voltage

What is the difference between copper and aluminum wire?

Aluminum has 61% the conductivity of copper and requires one gauge size larger for the same ampacity. A 20A copper circuit uses 12 AWG while aluminum needs 10 AWG. Aluminum is cheaper but requires special connectors.

Copper: Better conductivity, smaller diameter, easier to work with
Aluminum: 30–40% cheaper, lighter weight, requires larger gauge
Aluminum needs anti-oxidant compound at connections
Copper resistance: 10.37 ohm/1000ft for 12 AWG
Aluminum resistance: 16.51 ohm/1000ft for 12 AWG (1.6× copper)
