Trace Width
11.6 mils
mm
0.296 mm
Area
16.3 mil²
Minimum Trace Width
11.6 mils
0.296 mm
Cross-Section
16.3 mil²
Standard
IPC-2221
I = k × ΔT⁰ˢ⁴⁴ × A⁰ˢ⁷²⁵
As an Amazon Associate, we earn from qualifying purchases.
Price as of Jul 24, 2026. Product prices and availability are accurate as of the date indicated and are subject to change. Any price and availability information displayed on Amazon at the time of purchase will apply.
Inputs
Result
A = (1/(0.048×10^0.44))^(1/0.725) = 14.3 mil². Width = 14.3/1.4 = 10.2 mils.
Inputs
Result
A = (3/(0.048×10^0.44))^(1/0.725) = 37.2 mil². Width = 37.2/2.8 = 13.3 mils.
IPC-2221: I = k × ΔT^0.44 × A^0.725. Solve for area A, then width = A/thickness. For 1A on external 1oz copper with 10°C rise: width ≈ 10.2 mils (0.26mm).
| Current | 1oz External | 1oz Internal | 2oz External |
|---|---|---|---|
| 0.5A | 5 mils | 8 mils | 3 mils |
| 1A | 10 mils | 17 mils | 5 mils |
| 3A | 26 mils | 50 mils | 13 mils |
| 5A | 40 mils | 80 mils | 20 mils |
10°C is conservative and standard. 20°C acceptable for most boards. 45°C maximum per IPC-2221. Higher rise = narrower trace but hotter board.
External traces dissipate heat to air; internal traces are insulated by FR4. IPC uses k=0.048 external, k=0.024 internal. Internal traces need roughly 2x the width for the same current.
1oz copper = 1.4 mils (35µm) thick. 2oz = 2.8 mils. Thicker copper needs narrower traces for the same current since cross-section area = width × thickness.
